Core ChargeBolt holes for gasket surface = 17.Thickness at case where counter shaft bearing rides = 20.5mm.Counter shaft bearing = HGF 9486A, 75mm O.D. X 20.5mm Thick.Bracket for warmer plate = Yes.From top of case gasket surface to bottomof differential bearing pocket where differential race rides = 2.23-56.7mm.Has boss next to vent tube = No.FWD or AWD = FWD.Differential bearing race pocket for case side inside diameter is 81mm.SEE PICTURE...
Core ChargeBolt holes for gasket surface = 17.Thickness at case where counter shaft bearing rides = 20.5mm.Counter shaft bearing = HGF 9486A, 75mm O.D. X 20.5mm Thick.Bracket for warmer plate = No.From top of case gasket surface to bottomof differential bearing pocket where differential race rides = 2.23-56.7mm.Has boss next to vent tube = No.FWD or AWD = FWD.Differential bearing race pocket for case side inside diameter is 81mm.SEE PICTURE...
CORE CHARGE.Bolt holes for gasket surface = 20.Thickness at case where counter shaft bearing rides = 20.5mm.Counter shaft bearing = HGF 9486A, 75mm O.D. X 20.5mm Thick.Bracket for warmer plate = No.From top of case gasket surface to bottomof differential bearing pocket where differential race rides = 2.23-56.7mm.Has boss next to vent tube = No.FWD or AWD = AWD.Differential bearing race pocket for case side inside diameter is ??mm.SEE PICTURE...
Core ChargeBolt holes for gasket surface = 17.Thickness at case where counter shaft bearing rides = 20.5mm.Counter shaft bearing = HGF 9486A, 75mm O.D. X 20.5mm Thick.Bracket for warmer plate = No.From top of case gasket surface to bottomof differential bearing pocket where differential race rides = 2.23-56.7mm.Has boss next to vent tube = Yes.FWD or AWD = FWD.Differential bearing race pocket for case side inside diameter is 81mm.SEE PICTURE...
Core ChargeBolt holes for gasket surface = ??.Thickness at case where counter shaft bearing rides = 21.46mm.Counter shaft bearing = HGF 9486B, 81mm O.D. X 21.46mm Thick.Bracket for warmer plate = Yes.From top of case gasket surface to bottomof differential bearing pocket where differential race rides = ???-???mm.Has boss next to vent tube = No.FWD or AWD = FWD...
Core ChargeBolt holes for gasket surface = 17.Thickness at case where counter shaft bearing rides = 21.46mm.Counter shaft bearing = HGF 9486B, 81mm O.D. X 21.46mm Thick.Bracket for warmer plate = No.From top of case gasket surface to bottomof differential bearing pocket where differential race rides = 2.23-56.7mm.Has boss next to vent tube = No.FWD or AWD = FWD.Differential bearing race pocket for case side inside diameter is 81mm.SEE PICTURE...
Core ChargeBolt holes for gasket surface = 17.Thickness at case where counter shaft bearing rides = 21.46mm.Counter shaft bearing = HGF 9486B, 81mm O.D. X 21.46mm Thick.Bracket for warmer plate = No.From top of case gasket surface to bottomof differential bearing pocket where differential race rides = 2.23-56.7mm.Has boss next to vent tube = Yes.FWD or AWD = FWD.Differential bearing race pocket for case side inside diameter is 81mm.SEE PICTURE...
Core ChargeBolt holes for gasket surface = 20.Thickness at case where counter shaft bearing rides = 20.5mm.Counter shaft bearing = HGF 9486A, 75mm O.D. X 20.5mm Thick.Bracket for warmer plate = Yes.From top of case gasket surface to bottomof differential bearing pocket where differential race rides = 2.23-56.7mm.Has boss next to vent tube = No.FWD or AWD = AWD.Differential bearing race pocket for case side inside diameter is ??mm.SEE PICTURE...
Core ChargeBolt holes for gasket surface = 20.Thickness at case where counter shaft bearing rides = 21.46mm.Counter shaft bearing = HGF 9486B, 81mm O.D. X 21.46mm Thick.Bracket for warmer plate = No.From top of case gasket surface to bottomof differential bearing pocket where differential race rides = 2.82-71.8mm.Has boss next to vent tube = No.FWD or AWD = AWD.Differential bearing race pocket for case side inside diameter is 81mm.SEE PICTURE...
Bolt holes for gasket surface = 17.Thickness at case where counter shaft bearing rides = 20.5mm.Counter shaft bearing = HGF 9486A, 75mm O.D. X 20.5mm Thick.Bracket for warmer plate = Yes.From top of case gasket surface to bottomof differential bearing pocket where differential race rides = 2.23-56.7mm.Has boss next to vent tube = No.FWD or AWD = FWD.Differential bearing race pocket for case side inside diameter is 81mm.SEE PICTURE...
Bolt holes for gasket surface = 17.Thickness at case where counter shaft bearing rides = 20.5mm.Counter shaft bearing = HGF 9486A, 75mm O.D. X 20.5mm Thick.Bracket for warmer plate = No.From top of case gasket surface to bottomof differential bearing pocket where differential race rides = 2.23-56.7mm.Has boss next to vent tube = No.FWD or AWD = FWD.Differential bearing race pocket for case side inside diameter is 81mm.SEE PICTURE...
Bolt holes for gasket surface = 18.Thickness at case where counter shaft bearing rides = 21.46mm.Counter shaft bearing = HGF 9486B, 81mm O.D. X 21.46mm Thick.Bracket for warmer plate = No.From top of case gasket surface to bottomof differential bearing pocket where differential race rides = 2.82-71.8mm.Has boss next to vent tube = Yes.FWD or AWD = FWD.Differential bearing race pocket for case side inside diameter is 85mm.SEE PICTURE...
Bolt holes for gasket surface = 17.Thickness at case where counter shaft bearing rides = 20.5mm.Counter shaft bearing = HGF 9486A, 75mm O.D. X 20.5mm Thick.Bracket for warmer plate = No.From top of case gasket surface to bottomof differential bearing pocket where differential race rides = 2.23-56.7mm.Has boss next to vent tube = Yes.FWD or AWD = FWD.Differential bearing race pocket for case side inside diameter is 81mm.SEE PICTURE...
Bolt holes for gasket surface = ??.Thickness at case where counter shaft bearing rides = 21.46mm.Counter shaft bearing = HGF 9486B, 81mm O.D. X 21.46mm Thick.Bracket for warmer plate = Yes.From top of case gasket surface to bottomof differential bearing pocket where differential race rides = ???-???mm.Has boss next to vent tube = No.FWD or AWD = FWD...
Bolt holes for gasket surface = 17.Thickness at case where counter shaft bearing rides = 21.46mm.Counter shaft bearing = HGF 9486B, 81mm O.D. X 21.46mm Thick.Bracket for warmer plate = No.From top of case gasket surface to bottomof differential bearing pocket where differential race rides = 2.23-56.7mm.Has boss next to vent tube = No.FWD or AWD = FWD.Differential bearing race pocket for case side inside diameter is 81mm.SEE PICTURE...
Bolt holes for gasket surface = 17.Thickness at case where counter shaft bearing rides = 21.46mm.Counter shaft bearing = HGF 9486B, 81mm O.D. X 21.46mm Thick.Bracket for warmer plate = No.From top of case gasket surface to bottomof differential bearing pocket where differential race rides = 2.23-56.7mm.Has boss next to vent tube = Yes.FWD or AWD = FWD.Differential bearing race pocket for case side inside diameter is 81mm.SEE PICTURE...
Bolt holes for gasket surface = 20.Thickness at case where counter shaft bearing rides = 20.5mm.Counter shaft bearing = HGF 9486A, 75mm O.D. X 20.5mm Thick.Bracket for warmer plate = Yes.From top of case gasket surface to bottomof differential bearing pocket where differential race rides = 2.23-56.7mm.Has boss next to vent tube = No.FWD or AWD = AWD.Differential bearing race pocket for case side inside diameter is ??mm.SEE PICTURE...
Bolt holes for gasket surface = 20.Thickness at case where counter shaft bearing rides = 21.46mm.Counter shaft bearing = HGF 9486B, 81mm O.D. X 21.46mm Thick.Bracket for warmer plate = No.From top of case gasket surface to bottomof differential bearing pocket where differential race rides = 2.82-71.8mm.Has boss next to vent tube = No.FWD or AWD = AWD.Differential bearing race pocket for case side inside diameter is 81mm.SEE PICTURE...
